Figure 8.


Download original image

E-plane scan impedance for the 50th element versus angle of incidence for the infinitely replicated prototype antenna without (solid line) and with an homogenous anisotropic WAIM on top (dashed line). Red color stands for the real part while blue color line corresponds to the imaginary part.
